Características

Especificações

Modelo NÃO.: 3016

Sistema de resfriamento: Resfriamento de Água

Classe técnica: Laser de onda contínua

Material aplicável: Metal

Tipo de estrutura: Tipo de pórtico

Classificação do laser: Laser gasoso

Tecnologia a laser: Corte de falhas por controlo a laser

Sistema Gerador de Laser: Max 3000W

Sistema de Acompanhamento Aotomático: FSCUT

Banco de dados de processos de corte: Laser de energia estelar

Cabeça de corte manual a laser: Raytools

Esteiras porta cabos de alta flexibilidade, etc.: China

Identificador de controle remoto: CC Laser

Pacote de Transporte: caixa de madeira

Especificação: 3200*2500*1200MM

Marca registrada: StarPower

Origem: China

Código HS: 90132000

Capacidade de produção: 50

Destacar:

laser engraving machine for kitchen sinks

custom kitchen sink engraving machine

kitchen sink making machine with laser

Informação básica

Condições de Pagamento e Envio

Galeria

Advanced Laser Engraving Machine for Custom Kitchen Sinks

Descrição de produto

Product Description
Complete kitchen sink production line handmade sink manufacturing machine, the production line is a saving stainless steel material handmade sink manufacturing method. By splicing stainless steel sheets, the material utilization rate is improved, and the material cost of each sink is saved by about $1. At the same time, the investment in machinery and equipment is less, there is no need to customize the stamping die for the sink of different specifications and sizes, the production is flexible, the new product is put into production quickly and the investment is less. Manufactured kitchen sink high-grade and beautiful, and hot selling.
Advanced Laser Engraving Machine for Custom Kitchen Sinks 0

Process term	Process introduction	machine	Machine size	floor space		power (Kw)
Process term	Process introduction	machine	Machine size	Length(m)	Width(m)	power (Kw)
Process 1	Steel Coil Laser cutting	Laser cutter line	12000x2600x1950mm	17	2.6	45
Process 2	Sheet welding for Saving Material	Straight Seam Welding Machine	1400x1100x2000mm	1.4	1.1	0.4
Process 3	Sheet Grinding for Saving Material	Sheet Grinding Machine	2250x1550x1800mm	2.3	1.6	3.2
Process 4	Punching of water hole	Deep throat Press machine/J21S-40T	1500x1200x2000mm	1.5	1.2	4
Process 5	Punching for Prebending	Deep throat press machine/J21S-63T	1700x1400x2200mm	1.7	1.4	4
Process 6	Press the water line	Bending machine/30T-1600MM	2600x1400x2000mm	2.6	1.4	3
Process 7	Bending of the sink base	Bending machine/63T-2500MM	2800X1700X2350MM	2.8	1.7	5.5
Process 8	Press arc & bottom corner	Two-In-One Integrated Rolling Seam&Corner Pressing Machine	1300x750x2000mm	1.3	0.75	2.3
Process 9	Welding for vertical seams and bottom corner	CNC Welding Special Machine	1400x1100x2000mm	1.4	1.1	0.4
Process 10	Round corner Of vertical seams grinding (Inside)	Grinding Machine For Round corner Of vertical seams	2550x850x2200mm	2.6	0.85	2.3
Process 11	Repair the Panel's missing corners	CNC Welding Special Machine(for panel repair)	1100x850x1450mm	1.1	0.85	0.4
Process 12	CNC Welding For Panel's Inner Edge	Multi-Axis CNC Welding Special Machine (For panel's inner edge)	1700x1400x1600mm	1.7	1.4	1.3
Process 13	Grinding for the sink's panel	Grinding machine (Abrasive belt type)	2500x1400x1700mm	2.5	1.4	3
Process 14	Grinding for the sink's panel(mirror surface)	Grinding machine	3000x1400x1700mm	3	1.4	3
Process 15	Painting For Sink Bottom Back Side	Manual painting equipment	2200X1800X1600mm	2.2	1.8	4.5
Process 16	Drying after Painting	Drying Oven	13000X1000X1600mm	13	1	30
Total floor space(Includ spaced distance and transportation route):>65m(Length)x 10m(Width)

Our Advantages
Foshan is a famous metal manufacturing city with mature and advanced machine technology and reasonable prices,We focus on providing kitchen supplies production solutions, including providing production machines, plant layout, production technology output, for you to save worry, labor and money, we wholeheartedly escort your career success.
