High-Precision VSG-Series Vertical Seam Grinding Machine with Hydraulic Locking and Intelligent Control

1 conjunto
MOQ
negotiable
preço
High-Precision VSG-Series Vertical Seam Grinding Machine with Hydraulic Locking and Intelligent Control
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Especificação: De acordo com as pias
Destacar:

High-Precision Vertical Seam Grinding Machine

,

Hydraulic Locking Seam Polishing Machine

,

Intelligent Control VSG-Series Grinding Machine
Informação básica
Lugar de origem: Guangdong, China
Marca: Star Power
Certificação: CU, ISO
Número do modelo: VSG-500A
Condições de Pagamento e Envio
Detalhes da embalagem: Empacotamento de marinheiro
Tempo de entrega: 30-50 dias úteis
Termos de pagamento: L/c, t/t
Habilidade da fonte: 30 conjuntos/conjuntos por ano
Descrição de produto
PrecisionVert VSG-Series Vertical Seam Grinding & Polishing Machine
The InduHydraLock VSG-Series Vertical Seam Grinding Machine is a high-precision industrial equipment designed for grinding vertical seams in various metal workpieces. It features advanced hydraulic locking technology and intelligent control systems for stable, accurate grinding operations.
This machine is ideal for automotive manufacturing, aerospace, and metal processing industries. It handles steel, aluminum alloys, copper alloys, and other materials with excellent grinding quality and consistency.
The user-friendly interface and automated features simplify operation, reducing the need for highly skilled operators while improving production efficiency. Its robust construction and durable components ensure long service life with minimal maintenance.
High-Precision VSG-Series Vertical Seam Grinding Machine with Hydraulic Locking and Intelligent Control 0
Core Features
  • Achieves Ra 0.8μm ultra-fine surface finish through multi-stage grinding (coarse → fine → polishing)
  • Vertical clamping structure prevents workpiece deformation (ideal for thin-walled parts and fragile materials)
  • Adjustable grinding pressure (0.5-5bar) and variable speed grinding heads (500-3000rpm) for different material hardness
  • 3-5 times faster than manual processing with consistent accuracy (±0.02mm)
  • 7-inch touchscreen interface (B/C/D models) with preset parameters for quick setup
  • Built-in dust collection reduces emissions by ≥90%
Applications
Construction (curtain wall seams), automotive (body component seams), aerospace (light alloy part seams), home appliances (stainless steel tank seams), and furniture (stone countertop seams).
High-Precision VSG-Series Vertical Seam Grinding Machine with Hydraulic Locking and Intelligent Control 1
Technical Specifications
Parameter Category VSG-500A (Manual) VSG-1000B (Semi-Auto) VSG-1500C (Full-Auto) VSG-2000D (Heavy-Duty)
Processing Capacity Max seam length: 500mm
Seam width: 2-20mm		 Max seam length: 1000mm
Seam width: 2-30mm		 Max seam length: 1500mm
Seam width: 2-40mm		 Max seam length: 2000mm
Seam width: 5-50mm
Grinding System Speed: 1000-2000rpm (fixed)
Pressure: Manual (0.5-3bar)		 Speed: 800-2500rpm (adjustable)
Pressure: Pneumatic (0.5-4bar)		 Speed: 500-3000rpm (stepless)
Pressure: PLC (0.5-4.5bar)		 Speed: 500-2800rpm (stepless)
Pressure: Hydraulic (1-5bar)
Workpiece Clamping Manual clamp
Max thickness: 50mm		 Pneumatic clamp
Max thickness: 80mm		 Electric clamp with sensor
Max thickness: 100mm		 Hydraulic clamp with anti-slip
Max thickness: 150mm
Control System Mechanical knob 5-inch LCD 7-inch touchscreen + PLC 10-inch touchscreen + IoT
Power Supply 220V/50Hz; 1.5kW 380V/50Hz; 3kW 380V/50Hz; 4.5kW 380V/50Hz; 7.5kW
Certifications CE CE, ISO 9001 CE, ISO 9001 CE, ISO 9001
High-Precision VSG-Series Vertical Seam Grinding Machine with Hydraulic Locking and Intelligent Control 2 High-Precision VSG-Series Vertical Seam Grinding Machine with Hydraulic Locking and Intelligent Control 3
About Foshan Star Power Technology
Founded in 2022 and based in Foshan, China, we specialize in high-precision CNC technology and efficient production solutions. Our equipment enables laser cutting, bending, and welding operations for sink manufacturing and other metal processing applications.
Contact us today to discuss your production needs!
